10/100M PoE Injector IEEE802.3at 30W

Name: 10/100M PoE Injector IEEE802.3at 30W
Brand: E-link China Technology Co.,LTD
SKU: Lnk-poe200at
Price: 57.00 USD
Availability: InStock

Rincian produk

Tempat asal: Cina

Nama merek: E-link

Sertifikasi: CE, FCC, RoHS，ISO9001

Nomor model: Lnk-poe200at

Syarat Pembayaran & Pengiriman

Kuantitas min Order: 1 pcs

Harga: Negotiated

Kemasan rincian: Paket Ekspor Standar

Waktu pengiriman: 5-12 hari kerja

Syarat-syarat pembayaran: T/t, paypal

Menyediakan kemampuan: 1000 pcs/mulut

Dapatkan Harga Terbaik

Hubungi Sekarang

Spesifikasi

Deskripsi

Spesifikasi

Menyoroti:
                                                                                                                                                                                                                                                                                              IEEE802.3at PoE Injector


Suhu Operasi::	-10 ° C hingga 50 ° C (14 ° F hingga 122 ° F)	Rentang tegangan input::	100-240V AC @50/60Hz.
Dimensi (W × D × H)::	145 x 58 x 39mm	Berat:	0,25kg

Suhu Operasi::	-10 ° C hingga 50 ° C (14 ° F hingga 122 ° F)
Rentang tegangan input::	100-240V AC @50/60Hz.
Dimensi (W × D × H)::	145 x 58 x 39mm
Berat:	0,25kg

Deskripsi

10/100M PoE Injector IEEE802.3at 30W

PoE Injector Advantage

► Up to 30W of PoE Power

► Compliant with IEEE802.3af/at Standard

► Support 10/100Base-T

► Compliant with Limited Power Source (LPS)

► High Efficiency > 85%

► Low No Load Power Consumption < 0.5W

► Provide 2 LED indicators include Power LED(Green) and PoE LED(Orange)

PoE Injector Overview

LNK-POE200AT 30W – 48V Gigabit PoE Injector is a long-distance driving, fast network performing,

strong PoE Output IEEE802.3af/at certified midspan. It is a single port indoor PoE injector that can

provide up to 30W based on the IEEE 802.3af/at standard.

The midspans are ideal to power 802.11 access points, pan-tilt-zoom (PTZ) and dome cameras, IP

videophones, thin clients and other power Ethernet end terminals with 30W of power. The solutions

support IEEE 802.3af/at powered devices and are also backward compatible and safe to use with

any IEEE 802.3af/at terminal. With plug and-play installation, they are easy and cost effective to

implement leveraging existing Ethernet infrastructure while at the same time providing the assurance

of a future proof network.

PoE Injector Technical Indexes

Environmental
Operating Temperature:	-10°C to 50°C (14°F to 122°F)
Storage Temperature:	-20°C to 70°C (-4°F to 158°F)
Relative Humidity:	5% to 95% non-condensing
MTBF:	>200,000hrs
Electrical and Mechanical
Input Voltage Range:	100-240V AC @50/60Hz.
Output Voltage:	DC 48V
Power Consumption:	30 watts max.
PoE (Power over Ethernet)
Standard:	IEEE 802.3af
	IEEE 802.3at
Port:	RJ45
Pin Assignment	Data provide over pairs 1/2(+) and 3/6(-) Power over spare pairs 4/5(+) and 7/8(-)
PoE Power Output	DC 48V/30-watt PoE via 2-pairs
LED Indicators
Power:	Power Status
PoE:	PoE Status
Dimensions (W×D×H):	145 x 58 x 39mm
Weight:	0.25Kg
Casing:	Plastic Case
Mounting Options:	Desktop

PoE Injector Ordering Information

Model	Description
LNK-POE200AT	PoE Injector with Power Cord: 10/100Mbps, IEEE 802.3at 30W
