12G-SDI CWDM 1270 ~ 1610nm 10km Video Digital SFP Optical Transceiver

Name: 12G-SDI CWDM 1270 ~ 1610nm 10km Video Digital SFP Optical Transceiver
Brand: E-link China Technology Co.,LTD
SKU: LNK-CWDM-SFP12G-XX10
Price: 395.00 USD
Availability: InStock

Rincian produk

Place of Origin: China

Nama merek: E-link

Sertifikasi: RoHS

Model Number: LNK-CWDM-SFP12G-XX10

Syarat Pembayaran & Pengiriman

Minimum Order Quantity: 1 pcs

Harga: Dapat dinegosiasikan

Packaging Details: Carton Packaging

Delivery Time: 3-12 working days

Payment Terms: L/C,T/T,Western Union,MoneyGram,Paypal

Supply Ability: 1000 pcs/month

Dapatkan Harga Terbaik

Hubungi Sekarang

Spesifikasi

Deskripsi

Spesifikasi

Menyoroti:
                                                                                                                                                                                                                                                                                                                                                                                                      Transceiver optik 12G-SDI SFP, CWDM SFP transceiver 10km, Transceiver video digital 1270 ~ 1610nm


Transceiver Internal Temperature:	-5 to +70°C	VCC3 Internal Supply Voltage:	3.0 to 3.6V
Laser Bias Current:	0 to 90mA	Tx Output Power:	-5 to +4dBm
Rx Input Power:	-15.5 to +0.5dBm	Immunity:	IEC 61000-4-3

Transceiver Internal Temperature:	-5 to +70°C
VCC3 Internal Supply Voltage:	3.0 to 3.6V
Laser Bias Current:	0 to 90mA
Tx Output Power:	-5 to +4dBm
Rx Input Power:	-15.5 to +0.5dBm
Immunity:	IEC 61000-4-3

Deskripsi

12G-SDI CWDM 1270 ~ 1610nm 10km Video Digital SFP Optical Transceiver

12G-SDI CWDM 1270~1610nm 10km Digital Video SFP Optical Transceiver

Keuntungan

◎ Mendukung antarmuka optik serial 12Gb/s

◎ Hingga 10km transmisi pada SMF

◎ CWDM DFB laser dan penerima PIN

◎ SFP+ yang bisa dicolok panas

◎ SFI antarmuka listrik berkecepatan tinggi

◎ Fungsi diagnostik digital bawaan

◎ Sumber daya tunggal +3.3V

◎ Konsumsi daya kurang dari 1,0 W

◎ Suhu ruang operasi: -5~+70°C

◎ Paket SFP+ MSA dengan konektor LC dupleks

Gambaran umum

Transceiver SFP + adalah modul berkinerja tinggi dan hemat biaya yang mendukung kecepatan data 12Gbps dan jarak transmisi 10km dengan SMF.

Transceiver terdiri dari tiga bagian: pemancar laser CWDM DFB yang tidak didinginkan, fotodioda PIN yang terintegrasi dengan preamplifier trans-impedan (TIA) dan unit kontrol MCU.Semua modul memenuhi persyaratan keamanan laser kelas I.

Transceiver kompatibel dengan SFP Multi-Source Agreement dan fungsi diagnostik digital SFF-8472.

Informasi Pemesanan

Model	Deskripsi
LNK-CWDM-SFP12G-2710	12Gb/s SDI CWDM SFP Video Optical Transceiver, 1270nm, 10km, LC, DDMI, MSA
LNK-CWDM-SFP12G-2910	12Gb/s SDI CWDM SFP Video Optical Transceiver, 1290nm, 10km, LC, DDMI, MSA
LNK-CWDM-SFP12G-3110	12Gb/s SDI CWDM SFP Video Optical Transceiver, 1310nm, 10km, LC, DDMI, MSA
LNK-CWDM-SFP12G-3310	12Gb/s SDI CWDM SFP Video Optical Transceiver, 1330nm, 10km, LC, DDMI, MSA
LNK-CWDM-SFP12G-3510	12Gb/s SDI CWDM SFP Video Optical Transceiver, 1350nm, 10km, LC, DDMI, MSA
LNK-CWDM-SFP12G-3710	12Gb/s SDI CWDM SFP Video Optical Transceiver, 1370nm, 10km, LC, DDMI, MSA
LNK-CWDM-SFP12G-3910	12Gb/s SDI CWDM SFP Video Optical Transceiver, 1390nm, 10km, LC, DDMI, MSA
LNK-CWDM-SFP12G-4110	12Gb/s SDI CWDM SFP Video Optical Transceiver, 1410nm, 10km, LC, DDMI, MSA
LNK-CWDM-SFP12G-4310	12Gb/s SDI CWDM SFP Video Optical Transceiver, 1430nm, 10km, LC, DDMI, MSA
LNK-CWDM-SFP12G-4510	12Gb/s SDI CWDM SFP Video Optical Transceiver, 1450nm, 10km, LC, DDMI, MSA
LNK-CWDM-SFP12G-4710	12Gb/s SDI CWDM SFP Video Optical Transceiver, 1470nm, 10km, LC, DDMI, MSA
LNK-CWDM-SFP12G-4910	12Gb/s SDI CWDM SFP Video Optical Transceiver, 1490nm, 10km, LC, DDMI, MSA
LNK-CWDM-SFP12G-5110	12Gb/s SDI CWDM SFP Video Optical Transceiver, 1510nm, 10km, LC, DDMI, MSA
LNK-CWDM-SFP12G-5310	12Gb/s SDI CWDM SFP Video Optical Transceiver, 1530nm, 10km, LC, DDMI, MSA
LNK-CWDM-SFP12G-5510	12Gb/s SDI CWDM SFP Video Optical Transceiver, 1550nm, 10km, LC, DDMI, MSA
LNK-CWDM-SFP12G-5710	12Gb/s SDI CWDM SFP Video Optical Transceiver, 1570nm, 10km, LC, DDMI, MSA
LNK-CWDM-SFP12G-5910	12Gb/s SDI CWDM SFP Video Optical Transceiver, 1590nm, 10km, LC, DDMI, MSA
LNK-CWDM-SFP12G-6110	12Gb/s SDI CWDM SFP Video Optical Transceiver, 1610nm, 10km, LC, DDMI, MSA

Aplikasi

◎ 12GBASE-LR/LW 12G Ethernet

◎ Hubungan optik lainnya
