OSW Series MEMS Optical Switch

Name: OSW Series MEMS Optical Switch
Brand: E-link China Technology Co.,LTD
SKU: Lnk-osw
Price: 130.00 USD
Availability: InStock

Rincian produk

Tempat asal: CINA

Nama merek: E-link

Sertifikasi: CE, FCC, RoHS，ISO9001

Nomor model: Lnk-osw

Syarat Pembayaran & Pengiriman

Kuantitas min Order: 1 pcs

Harga: Negotiated

Kemasan rincian: Paket Ekspor Standar

Waktu pengiriman: 5-12 hari kerja

Syarat-syarat pembayaran: T/t, paypal

Menyediakan kemampuan: 1000 pcs/mulut

Dapatkan Harga Terbaik

Hubungi Sekarang

Spesifikasi

Deskripsi

Spesifikasi

Menyoroti:

Resolusi:	1920*1080@60Hz	Jarak:	Bergantung pada modul SFP+ yang digunakan, 20km direkomendasikan.
Catu daya:	12 ~ 48VDC (Non PoE) 48 ~ 57VDC (POE)	Ukuran:	150 x 115 x 50 mm
Berat:	0,6kg	Suhu operasi:	-40 ° C hingga 80 ° C (-40 ° F hingga 176 ° F)

Resolusi:	1920*1080@60Hz
Jarak:	Bergantung pada modul SFP+ yang digunakan, 20km direkomendasikan.
Catu daya:	12 ~ 48VDC (Non PoE) 48 ~ 57VDC (POE)
Ukuran:	150 x 115 x 50 mm
Berat:	0,6kg
Suhu operasi:	-40 ° C hingga 80 ° C (-40 ° F hingga 176 ° F)

Deskripsi

OSW Series MEMS Optical Switch

OSW Series MEMS Optical Switch

OSW Series MEMS Optical Switch Advantage

· 1 x 10G SFP+ fiber optical port

· 10 x Gigabit Ethernet ports, PoE optional

· supports RJ45 ports 10/100/1000M and Full Duplex/Half Duplex auto-negotiation

· Not support VLAN

OSW Series MEMS Optical Switch Overview

MEMS OSW is based on micro-electro-mechanical system (MEMS) technology, which achieved low insertion loss and highly repeatability by rotating the mirror of MEMS chip.

MEMS OSW is mainly used in optical cross and connection (OXC) system, optical add/drop system, measure instrument system and optical signal monitoring system.

The products are Telcordia GR-1312-CORE qualified, and RoHS ompliant.

OSW Series MEMS Optical Switch Technical Indexes

Parameter	Specification	Unit	Note
Wavelength Range	1260~1620	nm
Insertion Loss	1.0 & 1.2	dB	@1x4 & @1x8
Crosstalk	≥50	dB	For Single Mode
Return loss	≥45	dB	For Single Mode
Switching time	≤10	ms
Polarization Dependent Loss	≤0.2	dB
Wavelength Dependent Loss	≤0.3	dB	@<0 dB Att.
Return loss	≥45	dB	For Single Mode
Optical Power Handing	500	mW
Driving Voltage	60	V
Power Consumption	≤2	mW
Operation Temperature	-5~70	℃
Storage Temperature	-40~85	℃

OSW Series MEMS Optical Switch Ordering Information

LNK-OSW

LNK=E-link

O=Optical

S=Switch

W=MEMS

Port Configuration

Voltage Type

Switch Type

Wavelength

Fiber Type

Pigtail Type

Fiber Length

Connector

02=1x2

04=1x4

08=1x8

16=1x16

03=3V

60=60V

Non-Latching

1=1310nm

2=1550nm

3=1260~1620nm

4=850

1=SMF-28

2=MM50/125

3=62.5/125

X=Special

B=bare fiber

L=loose Tube

05=0.5m

10=1.0m

15=1.5m

0=None

1=FC/UPC

2=FC/APC

3=SC/UPC

4=SC/APC

5=LC/UPC

6=LC/APC
